    e30 2.5 and 2.7 stroker build help

    I love my e30 but the stock eta motor isn’t cutting it, what all is needed from a 2.5 for a stroker build and can I use 1991 pistons from a 325is?

    #2
    eta 81mm stroke crank
    eta 130mm rods
    m20b25 pistons (may need to trim the bottom of skirt depending which exact brand (KS or Mahle) they are as there is like 4 or 5 skirt lengths/types.
    deck block approx ~2mm
    adjustable cam gear (optional)
    m20b25 885 head
    272 cam (optional)
    M30 injectors or similar
    nice set of headers and exhaust (optional)
    chip or PNP ecu
    the rest from a m20b25
    89 E30 325is Lachs Silber - currently M20B31, M20B33 in the works, stroked to the hilt...

    new build thread http://www.r3vlimited.com/board/showthread.php?t=317505

    Comment


      #3
      Can you use 1991 325i lightweight pistons?

      Comment


        #4
        Originally posted by travis_e30 View Post
        Can you use 1991 325i lightweight pistons?
        M20b25 =Domed M50b25= Dished

        M50 pistons might work better with your stock head 773 but with 885 head your compression ratio will get down badly by almost 2.

        Digger gave you the perfect combination possible from 2.7 eta+2.5 i.


        Comment


          #5
          Originally posted by ADEN View Post

          M20b25 =Domed M50b25= Dished

          M50 pistons might work better with your stock head 773 but with 885 head your compression ratio will get down badly by almost 2.

          Digger gave you the perfect combination possible from 2.7 eta+2.5 i.

          1991 pistons from an m20 would work.
          john@m20guru.com
          Links:
          Transaction feedback: Here, here and here. Thanks :D

          Comment


            #6
            Originally posted by ForcedFirebird View Post

            1991 pistons from an m20 would work.
            MY bad i tought 91 was already e36.

            Comment


              #7
              Originally posted by ADEN View Post

              MY bad i tought 91 was already e36.
              The last e30's rolled off the line in Jan 1993. The e36 was built as early as Nov 1990. In the late years you would get an e30 if you ordered a vert, and an e36 otherwise since the verts had to go to Baur for the conversion. This is why the verts have diving boards longer than the others.
              john@m20guru.com
              Links:
              Transaction feedback: Here, here and here. Thanks :D

              Comment


                #8
                Originally posted by travis_e30 View Post
                Can you use 1991 325i lightweight pistons?
                All m20b25 pistons can be made to work essentially. If they are the lightweight they probably have the streamlined skirts. Here are some skirt types but there are others. The one on the right i think offers most clearance and is probably what you have.

                its easy to trim the bottom if you happen to have a longer skirt variant, just weight match them afterwards and removed burrs etc

                89 E30 325is Lachs Silber - currently M20B31, M20B33 in the works, stroked to the hilt...

                new build thread http://www.r3vlimited.com/board/showthread.php?t=317505

                Comment


                  #9
                  Thanks for the tips, these are the pistons I got- flat skirt 1991 late model “lightweight” pistons, these have more overall clearance than the m20b27 pistons and should work on the 2.7 crank.

                  Comment


                    #10
                    My setup from a little while ago. It's pretty solid. 288 cam though. I've pulled it and am going LS6TT, Tremec 6spd, why not. Thinking of putting the 2.7 in my Nissan D21 4x4. I love the sounds it makes with the Ansa and Schrick 288 on MS with the wasted spark setup/removed MAF.. Good luck on your build! 3.73 LSD is a game changer with the combo also IMO. I've saved the 2.93 gears for the upcoming build though.

                    1988SuperETA|Full I component swap|19lb injectors|Schrick 272|MSIIExtraBeta20071020|GM DIS Wasted Spark|LC-1
