Getrag 250 and what shift linkage???

[dude8383]

I have searched through the the 24V forums however I haven't found anything concrete.

So I followed what everyone says...

Use the shift carrier that comes with the tranny. My tranny didn't come with the carrier so I purchased that separately.

I have:

Getrag 250
E36 shift linkage

Problem is the linkage I have is too freaking short.

Does anyone have a p/n for the linkage they used and WORKED with their Getrag 250??

Thanks!!

[dude8383]

there is no one here that ran into this problem?

[dude8383]

bumping again.

[StereoInstaller1]

I bet your E36 linkage is ZF stuff.

[gregslow318i]

I used the stock e30 selector rod and I cut about and inch out of the center of it and taped both ends and used a pice of trended rod to make and adjustable on and just when back and forth trying to finding the right length then tacked it in to position will post a pic if I can find one

[hugh jass]

i have the 250 and am using a e36 325 rougue shift linkage. works fine. are you sure you have the right linkage?

[dude8383]

i have the 250 and am using a e36 325 rougue shift linkage. works fine. are you sure you have the right linkage?

would be able to give me the p/n for it?

what about measurements?

check out the pics attached.

the piece that is cut is the E36 stuff and the other piece is E30 318is linkage.

[MDryVur]

would be able to give me the p/n for it?

what about measurements?

check out the pics attached.

the piece that is cut is the E36 stuff and the other piece is E30 318is linkage.

sweet.. now some cutting on those bolts and bam...

[dude8383]

sweet.. now some cutting on those bolts and bam...

whoops i did forget to mention that i replaced the long bolts with something more reasonable!!

those were just for fitment hahahaha

but the shifter still isn't where i want it...or at least i think so because its kind of hard to gauge the positioning of the shifter when there is no steering wheel and seats in the car!! ah i think i will try it out this weekend though.

[dude8383]

bumping this up from the dead because i wanted to see if anyone get me something specific.

below is the linkage

now i want to know what the length of P/N 9 is, i'm interested in purchasing UUC's double sheer selector rod:

[bwh13]

I used carrier 25111221541 and shift rod 25111222664 with my G250/S52 swap. Each carrier has a number on the side that gives the center to center length (front mount hole to center of shifter hole). This one is 257.5mm

Shifter sits a little towards the front of the hole but not much.

[dude8383]

I used carrier 25111221541 and shift rod 25111222664 with my G250/S52 swap. Each carrier has a number on the side that gives the center to center length (front mount hole to center of shifter hole). This one is 257.5mm

Shifter sits a little towards the front of the hole but not much.

Wow, awesome. Thanks a bunch man. Going to order some more parts next week and maybe do this when I finish up my finals :)
