1971 BMW 1600 Project

Collapse
X

  • Time
  • Show
Clear All
new posts
  • rikaro
    Advanced Member
    • Nov 2012
    • 123

    #121
    very nice! subscribed

    Comment

    • 325i
      E30 Modder
      • Sep 2012
      • 910

      #122
      Originally posted by phreshkid
      Private space. We offer shop services only to close friends, and those who can pay. We mostly play with our own cars though.
      So awesome!
      1997 Audi A4 1.8t 5-Speed (bamboo metallic): ST Coilovers, Sport Edition 17x7.5 Et35, 215/45/17 Kumho AST, Panzer, Depo Ecodes, 55w 5k bulbs, Magnaflow 14815, Res delete, JHM Vent Boost gauge
      2001.5 Audi s4 2.7tt 6-Speed (Imola Yellow)
      <<Flickr>>

      Comment

      • quikveedb2
        R3VLimited
        • Sep 2007
        • 2258

        #123
        Great work man. I love that you're using the patina as a foundation for the other aspects of the cars "restoration", rather than something to be fixed. Sometimes I get frustrated with the dings, dents, and idiosyncrasies of my e30 but I have to remind myself how long it's been in service, & that each mark is a part of its history and character. You've got a good grip on your priorities and what you want the car to do, and I can appreciate that.
        Originally posted by Dozyproductions
        You know why you're drinking that Pabst? No its probably not because it was the first beer you grabbed. It's because you're a winner.

        Comment

        • phreshkid
          R3V Elite
          • May 2009
          • 4655

          #124
          Originally posted by SkiFree
          You'll be sitting at around 1.5°-ish negative camber which will be just fine for a sporty street car (Jeremy spent 10 years driving around with 3°). The trick is to make sure the car is corner balanced and your toe set at 1/16° in on either side.
          That's good to know! I hope to be driving this thing in a week or two. I would love to swap this week but I have to fly out to North Carolina tonight. Might be buying an M5.

          Originally posted by rikaro
          very nice! subscribed
          Thanks man!


          Originally posted by 325i
          So awesome!
          Gracias

          Originally posted by quikveedb2
          Great work man. I love that you're using the patina as a foundation for the other aspects of the cars "restoration", rather than something to be fixed. Sometimes I get frustrated with the dings, dents, and idiosyncrasies of my e30 but I have to remind myself how long it's been in service, & that each mark is a part of its history and character. You've got a good grip on your priorities and what you want the car to do, and I can appreciate that.
          OMG my heart skipped a beat. You're the greatest. But seriously, thanks. Lord knows I'm holding back from a full over-restoration.
          world renown Harry Potter expert
          sigpic

          Comment

          • delatlanta1281
            Dart Master
            • Mar 2006
            • 10317

            #125
            Glad the motor got there.... That alternated may be a single wire alternator, but I can't remember. Looks to have the IE large pulley on it though. I always wanted that valve cover. congrats on scoring it. You look inside the head yet?
            Yours truly,
            Rich
            sigpic
            Originally posted by Rigmaster
            you kids get off my lawn.....

            Comment

            • phreshkid
              R3V Elite
              • May 2009
              • 4655

              #126
              Originally posted by delatlanta1281
              Glad the motor got there.... That alternated may be a single wire alternator, but I can't remember. Looks to have the IE large pulley on it though. I always wanted that valve cover. congrats on scoring it. You look inside the head yet?
              PO says the alternator is a 60A unit with internal voltage regulator from an E21. Looks like the singe wire type. And the pulley is an IE unit. Right on both accounts. I have checked under the valve cover but I sure do like the old school cover! Wish I could swap the engine now but I'm out of town until Monday.
              world renown Harry Potter expert
              sigpic

              Comment

              • BobombETA
                E30 Mastermind
                • Apr 2008
                • 1575

                #127
                Love that you're keeping the patina. Just a great all around build.
                Instagram
                sigpic
                Current: 99 M3
                Past: 84 325e, 84 528e

                Comment

                • Tismael711
                  Mod Crazy
                  • Mar 2010
                  • 791

                  #128
                  The hell with "patina" ... paint the car. Everything else is new!

                  Comment

                  • delatlanta1281
                    Dart Master
                    • Mar 2006
                    • 10317

                    #129
                    Originally posted by Tismael711
                    The hell with "patina" ... paint the car. Everything else is new!
                    Don't do it man, I was going to paint mine, but with minimal to no rust, it's cool to have one with shot paint. People who don't know what my car is underneath it's exterior don't care to talk about it. Those who know what it is and inspect further are a blast to talk to. I'm headed down the same road with my e30. To the regular douche it just looks like an old dropped e30. To someone who knows what's up, it's a pretty fun car to discuss and drive.
                    Yours truly,
                    Rich
                    sigpic
                    Originally posted by Rigmaster
                    you kids get off my lawn.....

                    Comment

                    • phreshkid
                      R3V Elite
                      • May 2009
                      • 4655

                      #130
                      I don't really plan on painting the car....at least not for a year or three. I want to enjoy the damn thing but I keep pushing the date farther and farther back.


                      I'm about 94% ready to tear into the car and start replacing suspension components, brakes, engine, fasteners, etc., but I have yet to figure out the ignition system on this engine. I don't currently have a suitable distributor and buying one, then having it's timing custom curved to optimize the engine's internal components will be around $400ish. For about $200 more I can have a fully programmable ignition system that does away with the distributor altogether. It's basically Megasquirt but strictly for spark and timing. I like this idea.

                      I have no prior electrical experience and can't yet read wiring schematics, but I plan on taking the time and doing it right. I already know what I need and will be purchasing it shortly.

                      This will push the build back a week or three, but I can still do the bulk of everything else while I wait for the crank pulley, sensor housing and other custom made parts to arrive.



                      Sort of unrelated, these showed up:



                      I don't really plan on using any of it, but it's nice to have extras I suppose. Wait, I will actually use the starter. It's 9-10lbs lighter than the stock unit, fits perfectly, and is even smaller than the notorious s14 starter upgrade. I believe this is an m30 starter, but will confirm. The red fan might be used, but I do have a spal thin electric fan sitting in a box somewhere. May go ahead and install that as well.

                      These showed up today as well:





                      These are a one-year-only set of output shafts from a 1976 BMW 2002. These are slightly longer than standard 2002 output shafts and allow me to bridge the gap that occurs when swapping to the 320iS LSD unit. It's a direct drop in unit. Pretty cool.

                      That's all I have for now. I've been traveling a lot the last two-ish weeks and looks like I'll be doing a bit more. I'll keep you guys updated.


                      If I had a goal of when to have this thing running and driving at a level I consider satisfactory, I'd say before Bimmerfest.
                      world renown Harry Potter expert
                      sigpic

                      Comment

                      • CorvallisBMW
                        Long Schlong Longhammer
                        • Feb 2005
                        • 13039

                        #131
                        that's a goofy looking fan, the blades aren't even spaced out evenly. How is it balanced?

                        Comment

                        • LJ851
                          R3V OG
                          • Nov 2010
                          • 7918

                          #132
                          Originally posted by CorvallisBMW
                          that's a goofy looking fan, the blades aren't even spaced out evenly. How is it balanced?


                          Science.
                          Lorin


                          Originally posted by slammin.e28
                          The M30 is God's engine.

                          Comment

                          • SkiFree
                            R3VLimited
                            • Jun 2011
                            • 2766

                            #133
                            Originally posted by LJ851
                            Science.
                            ADAMS Autosport

                            Comment

                            • phreshkid
                              R3V Elite
                              • May 2009
                              • 4655

                              #134
                              A little earlier than expected, but I'm going to be running Megajolt Ignition System.

                              Reasoning: I still don't have a suitable distributor for this engine. I figure that I will have to buy another one, then send it out for a custom timing curve that will help match the engine. An IE unit will probably work just fine, but I can't help but wonder what kind of power delivery and engine smoothness I'm leaving on the table.

                              With the Megajolt system, I'm able to rid myself of the distributor. This will free up a bit of power being as the engine no longer has to turn the dang thing. I will also be able to program different timing curves, depending on what the driving situation allows. I can have a timing curve for daily driving, and another for racecar driving, pending what the car is needed for.

                              Is it necessary? No, not really. Is it a worthwhile upgrade? Considering I don't want to deal with a distributor ever again, and enjoy the smooth operation of a more modern ignition system (with horsepower gains!), I'd say yes.

                              This will set the build back a few weeks as the 36-1 crank wheel that my buddy Tom at 02Again.com sells, just ran out and won't be produced for another few weeks.

                              But still, I'm excited. By the way, I can't so much as read an electrical schematic. Time to Khanacademy for a little while.





                              Edit: I may still run a dizzy. I'll know more by next week.
                              Last edited by phreshkid; 04-04-2014, 07:35 PM.
                              world renown Harry Potter expert
                              sigpic

                              Comment

                              • phreshkid
                                R3V Elite
                                • May 2009
                                • 4655

                                #135
                                Today I finally put her on the lift and began tearing her apart. I figured it would be easier to lower the engine and tranny from below, along with the front subframe. This way I can change out any suspension bushings I see fit, and get into all of those hard-to-reach places. And also because I was lazy.

                                Anyways, Here are a few photos of what I was able to get done today:

                                Hood removed and positioned on the lift:


                                Before shots of engine bay, one last look at the 1.6l:


                                Things are coming apart and almost ready to drop the engine:


                                A few minutes later and I have this view. There is no turning back now. Good thing I have a very competent mechanic friend.






                                I also managed to swap in a set of 1976 output shafts into the e21 320iS lsd unit. 3.91 and a 4 speed is going to be really fun, but not very practical. I should find a 5 speed soon.





                                I should have more photos tomorrow. In the meantime, my competent mechanic friend put together this cool engine stand. He rebuilt the engine from our Mercedes Pagoda project and ran it on the stand. Everything works as it should. He's good at what he does.





                                Scope creep is really setting in. For the sake of wanting to drive this thing, I'll likely grab a dizzy and a few other things. This will at least let me drive it and iron out all the kinks while I put the Megajolt system together.

                                More photos to follow tomorrow!

                                Everything driveline and suspension related will be new and improved somehow.
