LIFETIME warranty on workmanship with proof of purchase.
Want to get your swap finished quicker? These adapters will save you a lot of headaches and hassle.
We now offer an A/C solution for the M52TU, M54, S54, M62, M62TU, and S62 swaps.
These can be prewired into the harness adapter, or added on separately if you already have a harness adapter.
Message or Email us for more information.
https://www.redline-motorsport.com
You can reach us at: sales@redline-motorsport.com
All additional options are included in the prices. All standard relays and fuses are included (With an exception of the S54/S62 EKP Module)
NLA connectors such as (E12/E21/E30 Square C101, C104, Z3M S54) will be high quality reproductions to allow for a simple Plug-and-Play solution. If we have a used connector available, we will use those before the reproduction style. No extra rewiring will be required.
M50, M52(single vanos), S50 (US and Euro), S52
(For E36, E34, Z3 engine harnesses)
$180
*If you plan to use the E39 obd2 harness for the M52(single vanos), we have a separate listing for that style (see website for details).
These include the following options:
. • OBD1 (M50/S50 harness) or OBD2 (M52/S52 harness)
. • Cluster coolant temperature Wiring
. • C104 Wiring (82-87 models)
Options:
. • Oil level sensor wiring
. • A/C input wiring
. • ABS power wire if you have a 90+ model
. • Oil temperature wiring if you have an e30 M3 or the e30 M3 cluster
. • OBD2 diagnostic ports are available as well for the M52 and S52 engines (Special request)
--------------------------------------------------------------
M52TU, M54, S54, M62TU and S62
*Required ECUs for these harnesses are the following: MS42, MS43, MSS54 or MSS54HP, ME7.2, MSS52**
We can make these for the E46, E39, or Z3M harness.
$365
These include the following:
. • Cluster coolant temperature wiring
. • Fuel pump relay wiring (The S54/S62 use PN# 61357892976. If you rather have a standard relay, please let us know so that we can make that change)
. • OBD2 diagnostic port
. • Sport button for the S54 and S62
. • Electronic pedal connector for the M54, S54, M62TU, and S62
Options:
. • A/C module ($200) - Made by us at Redline-Motorsport
. • Secondary Air Pump relay and wiring
. • Oil level sensor wiring (Except S54, M62TU, or S62) *Unless you request it*
. • ABS power wire if you have a e30 1990 and newer models
. • Oil temperature wiring if you have an e30 M3 or the e30 M3 cluster
EWS must be deleted from your DME.
--------------------------------------------------------------
ECU Tuning
$75 (EWS Delete is FREE with a harness purchase).
EWS deletes available for the following:
. M52TU (MS42)
. M54 (MS43 B22, B25, or B30)
. S54 (MSS54 or MSS54HP)
. S62 (MSS52)
Additional options:
. Secondary Air Pump Delete
. Rear o2 Delete
. Cat Delete
. Top Speed Delete
. VSS removal
. Rev limit adjustment
. Sport Mode Memory
You will just need to send us your ECU to be modified.
--------------------------------------------------------------
M60, M62 obd1 converted
**Intended to be used with the E34 engine harness with the round X20 connector.
$180
These include the following options:
. • Oil level sensor wiring
. • A/C input wiring
. • ABS power wire if you have a 90+ model
--------------------------------------------------------------
M60 (E38 version without round X20)
$275
These include the following options:
. • Oil level sensor wiring
. • ABS power wire if you have a 90+ model
--------------------------------------------------------------
M62 (Post 97)
(Intended to be used with the ME5.2.1 ecu, part# 1437284) (5 ECU plugs)
$365
These include the following:
. • Cluster coolant temperature wiring
. • Fuel pump relay wiring
. • OBD2 diagnostic port
Options:
. • ABS power wire if you have a e30 1990 and newer models
. • A/C module ($200) - Made by us at Redline-Motorsport
These DO NOT include A/C wiring.
EWS must be deleted from your DME.
--------------------------------------------------------------
M62 (Pre 97)
(Intended to be used with the 474 ECU, Bosch ME5.2) (1 single ECU plug)
$275
These include the following:
. • Cluster coolant temperature wiring
. • Fuel pump relay wiring
. • OBD2 diagnostic port
Options:
. • ABS power wire if you have a e30 1990 and newer models
These DO NOT include A/C wiring.
EWS must be deleted from your DME.
--------------------------------------------------------------
N52 and N54 (Includes CAN-Bus module)
*Required ECUs for these harnesses are the following: MSV70, MSV80, MSD80/MSD81
We can make these for the E60/E61 and E90/E91/E92/E93 harnesses.
$500
These include the following:
. • Cluster coolant temperature wiring
. • Fuel pump relay and wiring
. • OBD2 diagnostic port
. • Electronic pedal wiring
. • CAN-Bus emulator module
Best paired with a matching set of the following:
- DME
- CAS Module with ribbon
- Key and key reader
However, if you decide to get an EWS/CAS delete, a matching set will not be required. Several companies offer this service now. Message for referrals.
--------------------------------------------------------------
Benchflash harness for MS42, MS43, MS45, ME7.2, MSS54/HP, and MSS52
$85.00
We do offer an ECU benchflash harness to reflash your DME outside of the car.
It will come with instructions and links for the necessary software.
It is intended to be used with any 12v power supply. It is suggested to use one that only reaches 5 amps maximum. Otherwise, I suggest to add a fuse to the (+) terminal on the benchflash harness.
You will just need to get an INPA K+DCAN cable and/or Galletto 1260 cable. These options are explained in the included instructions.
Radiator/Auxiliary fan wiring is now available. This wiring is intended for the E30, E36, or E46 original auxiliary fans.
The E30 and E36 fans will need to be used with the 88/80c radiator temperature sensor, part# 61318361787.
If you have another option in mind, contact us to see if we can provide a harness for your setup.
For pictures, please refer to the website. We are continuously adding to our website.
https://www.redline-motorsport.com
We can make conversion kits for the E9, 1602, 2002, E12, E21, E24, E28, E30, E34, E36, Z3, E39, and E46 chassis.
