M50T shake down drift day pix

[shiboujin]

No one got any of me moving. There is an in car video or two but it is still being uploaded.

Found on http://picasaweb.google.com/JDorisan13/HyperFest09#


Thanks Jordan!







I should probably give back story. This was summit point (6/20) and I signed up for drift 101 (lol). The main point was to make sure the motor was solid, didn't leak, and wouldn't blow up when driven hard. I scrambled to get the car ready but didn't have time for a decent alignment. Lots of other non motor related problems but the motor held strong. I do have overheating problems thanks to the stock M20 clutch fan and 325i radiator but those are near future upgrades. I'm happy with the motor but I have work to do to the rest of the car.

Big ups to Erick for getting me the steering rack spacers. I doubt they helped but it will in the near future.

[Erik]

Lol sweet hood notch.

[shiboujin]

haha thanks. I used to regret doing it but it caught so many eyes and had people stopping by to ask about the car when i was sitting in the paddock after my runs.

[Wh33lhop]

Nice. Got a dyno graph? Numbers, weight, suspension, chassis, brakes?

[shiboujin]

The place that tuned my car didn't give me a dyno graph but it hit about 265 whp and 240wtq at 8psi but I have an exhaust leak pre turbo. Weight is est 2400-2500.

Suspension is cosmo coils and HR 19/22 sways. nothign too fancy. Brakes are stock.

Heres a generic mods list that I haven't updated in a bit.

Mods:
Motor:
M50B25 Non-Vanos out of a 1990 525i
0.0140" MLS head gasket
Yoshi refreshed
Holset HX35W with non WG housing
Ebay WG
Random BOV
Megasquirt 1 V3 running wasted coil on plug (BIP373 upgrade)
Ford Racing 42# injectors
Walbro 255 fuel pump
Yoshi wiring harness
Ebay bottom mount turbo manifold made top mount
3" exhaust with bolt on cutout
Biggest ebay FMIC I could find
NGK bp???7E spark plugs gapped to 0.030"

Drivetrain:
2.93 LSD from an E28
ZF 310D transmission
97 M3 drive shaft
Spec Stage 4 unsprung clutch
B&M short shifter

Suspension:
Cosmo Coilovers (forget the spring rates)
K-Mac camber/caster plates
IE sways (22mm front and 19mm rear IIRC)
solid sway links in the front (probably a bad idea according to zack)

Wheels:
17x8 +20 sportmax 006 running 225/40/17 Falken RT 615s
17x9 +25 sportmax 006s on the rear with shit tires

Interior:
MoMo steering wheel
MoMo shift knob
Sparco warrior seat
Autopower 6 point bolt in cage

Other:
SS brake lines (4 out of 6... got lazy)
axis brake pads (are gay)
E28 motor mounts
E21 tranny mounts
Zionsville autosport modified brake booster

[Wh33lhop]

Pretty good, but your wheel fitment sucks. :( Hard to believe those are +25.

[BTP325ic]

-20

[shiboujin]

Actually, those aren't the rims on my mods list. they are some enkeis my brother had. With the tie rod spacers i put in and the sheer size of the tires they rub on the side of the fender well. I have some THR cabs going in soon that should push the wheel forward enough to run them.

those enkeis suck and the penero zeros on them had so little grip it wasn't funny.

[e30slut]

that shit sounds like fun..... unsprung clutch ftw

[shiboujin]

Surprisingly, I could daily that clutch. It wasn't as bad as I was expecting.. maybe I installed it wrong?

[e30slut]

they do tend to make them seem like they're just horrible daily driving clutches. It's not the feel that they are bitchin about, its the fact of how fast thet clutch will burn up trying to daily it...

[shiboujin]

Precursor, It makes me really really sad that I can drift other ppls cars better than mine. I partially blame myself as a driver and partially myself as a mechanic (the sway bar problem and shitty alignment). Basically I blame myself all around. I suxors...

The good tho, Whenever you hear my shift out of second I'm doing 60+mph. Note how fast my car gets there even with wheel spin between gears. Also my exhaust sounds AWESOME when I'm not redlining it.

On to the sucking...

http://vimeo.com/5275619

http://vimeo.com/5275786

http://vimeo.com/5275929

Odd switchback behavior from 1:08-1:15. I'm 100% off of every pedal and the wheel.

Thanks sach for taking video. I owe you a BJ

[aschroeder92]

Oh herro Yoshi :D

[MR 325]

Was that your first time drifting?

[ubernasty]

what a bucket. :)

i'm pissed i missed hyperfest this year...


edit: wtf yoshi? are those 3 vid's being serious? i hope you uploaded the 3 worst runs of the event... i seriously thought you could actually drift from the talk and yada yada comments that you always leave on forums. (not hating just asking, what's up man)
