    Euroweave and RZ project...as a set!

    Hello friends.

    Ive been wanting to run this setup for a few years but never wanted had an opportunity nor wanted to part with the cash. I decided that I needed to start sooner than later because E30 parts are getting harder to find and more expensive. So my quest was to find (2) 15x7 BBS RZ378 ET20 wheels. I had a feeler out which led me to these.



    Wait, wait, wait….why only 2….you ask? Ill get to that but here is a peek of what im up to. As you will see, I happen to have 2 euroweaves laying around for just an occasion…in very poor shape but workable. The euroweaves had to be straightened but not too bad, just some adjustments needed by a pro. A little curbage was present but not terrible. These will never be perfect but it will work for me.


    Ok, back to the RZs and the refinishing part. For the lips, I had to start from scratch. I wanted to see how much work it would be to get the lips polished. But first I had to remove the failed clear. I happen to have some thinner laying around in the garage so I tried it on a spot.



    Once removed, some shine was noticed.



    I was surprised to see how well they came out but there were deeper scratches in the metal so I now had a plan. First remove the clear only from the lips, wetsand, 320, 400, 600, 800, 1K, 1.5K, 2k, polish.

    Hours and hours later I wanted to compare lips and get an idea if my setup is what I was going for. Im on the right track!



    Prepped the RZs and used tack cloth…


    Paint…


    clear…


    And BAM, baller!!!


    I didn’t take many pix before this as I was thinking of shipping these out to get finished but it was easy enough to do in my garage. Just a lot of labor. That’s one, 3 more to go.

    Like I showed before, I used some Crown Paint remover. There were a few part of the 2nd RZ that were not coming off so I went to the ol’ reliable…Aircraft paint stripper.



    This worked marginally better. I think that the clear coat was pitted in the metal. More work for sanding was needed. After all the clear was removed from the lips, now it was time for the sanding. First, 320 grit. The whole lip was done but after each grit, I tested out the look with the Mothers metal polish just to see how it was going. So a sample will be shown from here on out.



    400…

    600…

    800…

    1K…

    1.5K…

    2K…

    And all poished…


    Amazing, right!?!?


    Now it was time to get the euroweaves up to spec of the RZs. As you can see the lips have failed clear as well but the good news is that they were polished originally…not painted like I have now. Trying to remove OEM paint is not a DIYer if you (like me) don’t have a blast cabinet in my garage. The Aircraft stripper laughed at it on one sample section.

    It takes a steady brush to apply just on the edge of wheel color and metal. I wasn’t 100% perfect but it worked for me. But the clear was on tight. It took a few applications to get it off.

    Just for S-n-Gs I tried to hit the wheel with sone walnut shells for a better paintable surface. I was tired of these wheels laughing at me L

    All lips polished. :up:

    Primer, Wurth silver, clear…

    Drying…

    I know the wait is killing ya! :lol






    Done! These are exactly the look I wanted. I have only seen 2 cars run this setup and should be mounted next week to my cabrio.


    Thanks for looking.
    Cheers!
    Last edited by N2MYE30; 05-03-2013, 05:05 AM.

    COTM
  • willworkfore30s
    E30 Enthusiast
    • Aug 2011
    • 1090

    #2
    What a clever idea. Can't wait to see finished product one the ???vert????
    sigpic

    Comment

    • N2MYE30
      R3V Elite
      • Oct 2007
      • 5536

      #3
      Yeah, they are going on the cabrio hopefully sometime next week.

      COTM

      Comment

      • lambo
        Captain Scene Points
        • Feb 2010
        • 10953

        #4
        Oh man... I am SO jealous! I have wanted to do this exact same thing for a while now...

        Originally posted by SpasticDwarf;n6449866
        Honestly I built it just to have a place to sit and listen to Hotline Bling on repeat.

        Comment

        • reelizmpro
          R3V OG
          • Dec 2003
          • 9446

          #5
          Good job. Did u prime them before u sprayed them? Given the cost of refinishing wheels I might just do my euroweaves myself.
          Last edited by reelizmpro; 05-01-2013, 12:23 PM.
          "I'd probably take the E30 M3 in this case just because I love that little car, and how tanky that inline 6 is." - thecj

          85 323i M TECH 1 S52 - ALPINEWEISS/SCHWARZE
          88 M3 - LACHSSILBER/SCHWARZE
          89 M3 - ALPINEWEISS II/M TECH CLOTH-ALCANTARA
          91 M TECHNIC CABRIO TURBO - MACAOBLAU/M TECH CLOTH-LEATHER

          Comment

          • dude8383
            Forum Sponsor
            • Jan 2005
            • 10387

            #6
            What an awesome idea... its staggered but not!
            IG: deniso_nsi Leave me feedback here

            Comment

            • Garageaholic
              Freestyle Fabricator
              • Dec 2005
              • 5204

              #7
              Wow. Excellent idea. Can't wait to see these mounted.
              Recent Rebranding!!
              Visit Garageaholic for all of your E30 Swap Needs!
              E30 SM62/S62
              E30 M60 V8
              E30 M30 Big 6!




              Check out this E36 N54 Swap Build
              Instagram.com/garageaholic
              Youtube.com/garageaholic

              Comment

              • N2MYE30
                R3V Elite
                • Oct 2007
                • 5536

                #8
                Thanks. Yep, they were primed. Having these done by a pro would have hurt, hence why I did them myself. I already have a lot in them.

                COTM

                Comment

                • Luis325
                  No R3VLimiter
                  • Jun 2009
                  • 3847

                  #9
                  Want to see pics!
                  sigpic
                  1986 "C2 2.7 Alpina" Sedan
                  1987 325ic Black Vert
                  1986 327i Red Track Car RIP 10/10/10
                  1989 325is Henna S50 track car SOLD


                  Transaction feedback here please!!
                  http://www.r3vlimited.com/board/showthread.php?t=170548

                  Comment

                  • straight6pwr
                    No R3VLimiter
                    • Sep 2004
                    • 3450

                    #10
                    cool project. they are identical in style except the convex face of the RZ, so they match pretty well.

                    i did the same with a full set of euroweaves and man do they look great after the refinish.

                    Comment

                    • getouth
                      No R3VLimiter
                      • Jan 2010
                      • 3343

                      #11
                      ^^^+1
                      FEEDBACK:
                      http://www.r3vlimited.com/board/showthread.php?t=316212

                      BMWCCA #398608
                      IG @yagayo38

                      "The Best E30's were built with two camshafts four cylinders and sixteen valves!".

                      Comment

                      • illest318i
                        E30 Fanatic
                        • Mar 2011
                        • 1472

                        #12
                        Wow they came out great! Any pics on the cabrio yet?
                        IG: @_j.wn

                        Comment

                        • Northern
                          R3V Elite
                          • Nov 2010
                          • 5040

                          #13
                          +1 For this setup! I find an 18-20mm spacer in the back(with a slight roll) and a 20mm spacers up front do wonders for it.

                          (pic with 12mm spacers up front, 20mm rear)
                          Last edited by Northern; 05-11-2013, 04:47 AM.
                          Originally posted by priapism
                          My girl don't know shit, but she bakes a mean cupcake.
                          Originally posted by shameson
                          Usually it's best not to know how much money you have into your e30

                          Comment

                          • Pipes
                            E30 Addict
                            • Aug 2012
                            • 485

                            #14
                            In for pics mounted! Awesome job on those!!
                            1991 349is (wadded up)
                            1984 Rabbit 2.0L16v swap (wife's)
                            2003 LR Disco II (wife's)
                            1993 MB 400SEL (son 1's)
                            1980 MB 450SEL (son 2's)
                            2004 KTM 525 EXC-R SM Sold:(

                            Comment

                            • word is bond
                              E30 Addict
                              • Apr 2012
                              • 503

                              #15
                              Also in for photographs. This is going to look fantastic...
