    Another fan question (thinking about running a single fan)

    Hi r3v, I want to apologize in advance for the flaming I'm probably going to get because this topic is likely beaten to death. But truthfully I wasn't able to find any decent information on this and I did search the site and google as well.

    In any case, with my current M20 setup, I am just running a stock mechanical fan clutch with no aux fan. I'm swapping in an S50US motor. Now I know I'm likely going to have no room for a mechanical fan clutch at the front of my engine after it's swapped, so my question is would I be OK with just running a single fan (in place of where my aux fan used to be) to cool the engine and just deleting my mechanical fan clutch? Or would I definitely need to run both a thin electric fan where my mechanical fan clutch used to be, and also re-install my aux fan?

    Worth noting that I do not and will not have AC. Also I will be running a standard size radiator, so not doing the M42 small radiator with the integrated tank.

    Thanks

    #2
    Hello buddy,i currently have a big single spal fan on my M50,where the aux was...Even with the small M42 radiator and with Greece's high ambient temperature during summer,it always stay at optimal level. Im using a Thermostat switch from a E36 with air con (if u are interested i can tell you the PN,right now the car is at my workplace,i ll go tomorrow there)...
    Instagram

    Comment


      #3
      Same here, but with an M52. I would have preferred the clutch fan, but it's a bit tight so I've been running a single electric fan.
      The fan has been doing its job perfectly since installing it 6 years ago.
      Also standard size radiator here, and no A/C.

      Comment


        #4
        Originally posted by 323i E30 View Post
        Same here, but with an M52. I would have preferred the clutch fan, but it's a bit tight so I've been running a single electric fan.
        The fan has been doing its job perfectly since installing it 6 years ago.
        Also standard size radiator here, and no A/C.
        Thanks for the feedback! Are you running your electric fan as a pusher in front of the radiator, or as a puller where the mechanical fan clutch used to be? Also which model fan did you go with?
        Last edited by mike87; 05-08-2020, 12:08 AM.

        Comment


          #5
          It's a pusher fan. I don't remember the brand of it.
          I did have an issue with the cooling system 2 years ago, but that was not fan-related. You can see the setup in the video I made back then.
          (Flushing the engine solved that by the way)

          Comment


            #6
            Maybe you can use the mechanical e30 fan with an e30 radiator, or just the puller? I couldn't fit a puller fan with the larger e36 radiator and certainly not the mechanical, so I just use a single pusher, the SPAL 16in that's rated for 1600 cfm.

            Comment


              #7
              Thanks everyone! Appreciate the feedback

              Comment


                #8
                Originally posted by mike87 View Post
                Thanks everyone! Appreciate the feedback
                You want to read this thread, also I would use the oem e36 pusher fan over the aftermarket stuff. Good luck!

                https://www.r3vlimited.com/board/for...-wiring-thread

                Comment


                  #9
                  The diesel m21 mechanical fan works with the mishimoto radiators if you really want to keep the clutch type setup. Get the lower temp rad switch to kick that aux fan on earlier as well.
