The Official Engine Bay Photo Thread

[MR E30 325is]

Dos 24v's

[cmybimmer]

I was out by my car taking photos of the EMS so I took one here too. Dirty ass engine bay.

Gahhh I want boost... One day...

Not nearly as clean as majority of the engine bays in this thread, but here's mine

[Crodell6]

Just started

[619E30]

Here's what I have until I can get a hold of my laptop and upload the actual engine bay.

[OldDrunkenSailor]

Just started

I've had a hydroboost in mine for so long, everytime I see the old master cylinder in there it makes me pause and go "whaaaa?"

Are you going to repaint or just powerwash?

[iwantspeed]

before

after

cosmetic modifications
Sparco bar
throttle bracket modified to use cruise control and sparco bar.
e30 m3 wiring harness bracket
e30 m3 harness cover
shortened engine wiring loom/harness
relocated relays and diagnostic port to firewall


future plans
passenger side frame rail top cover
relocate the diagnostic port bracket down below and out of view

[acolella76]

before
after

cosmetic modifications
Sparco bar
throttle bracket modified to use cruise control and sparco bar.
e30 m3 wiring harness bracket
e30 m3 harness cover
shortened engine wiring loom/harness
relocated relays and diagnostic port to firewall


future plans
passenger side frame rail top cover
relocate the diagnostic port bracket down below and out of view

Looks extremely clean. Move your coil to behind the headlights.. Would look great.

[warioware]

mine so far

[MR 325]

That engine looks like it's leaned very far to the driver side.

[Crodell6]

[/RIGHT]ailor;2793432]I've had a hydroboost in mine for so long, everytime I see the old master cylinder in there it makes me pause and go "whaaaa?"

Are you going to repaint or just powerwash?

Shaved bay is what I'm going for. Here's a more updated pic but not current. I got bondo and fiberglass in there now.


And also taking the opportunity to foam the chassis...

[Wishno87]

mine so far

Are you somehow using M20 motor mount arms?

[Crodell6]

Are you somehow using M20 motor mount arms?

It does look like it if u zoom into the pass. side motormount

[warioware]

nope im using e24 engine mounts and using the original arms from the s50..swap is still in progress so this isn't the way it will sit once its done

[warioware]

i just spoke with my mechanic and he did use m20 motor mount arms he told me that the m3 motor mount arms were too long

[Crodell6]

More progress
