84 325e m50 plastic bumper swap: Now on Catuned coilovers

Collapse
X

  • Time
  • Show
Clear All
new posts
  • Rdreas
    Advanced Member
    • Aug 2013
    • 164

    #46
    So not a ton of work done to the e30 as of recent. Ive been blowing my money on other things but they do kind of relate. I wasn't happy with the height the fronts gave me when they were all the way down sooooo I cut them up and went super low.
    IMG_20151018_144604 by Rdreas, on Flickr
    Much happier with my new all the way down height!
    Snapchat-785655008499399442 by Rdreas, on Flickr
    Probably not going to be this low or on these wheels but I like to know I could if I wanted to!
    On to the other things Ive been using e30 funds on
    IMG_20151001_131329 by Rdreas, on Flickr
    Bridgeport with autofeed and an indexing table.
    And then a friend was selling these on the super cheap so I had to jump on them, Ssr koenigs
    IMG_20151012_185558 by Rdreas, on Flickr
    18x9.5 squared setup et 29. 2 have bent lips which is why they were so cheap.I wanted to see what they looked like on the e30 but would need some big fat adapters to get any sort of idea, but I do have some smaller lips for the front to make them 8.5" and bigger if I wanted to go to a 10.5" rear.

    Comment

    • FreedomM3
      Advanced Member
      • Aug 2015
      • 191

      #47
      This thread is full of awesome! Great progress on the car! Hopefully I can get the funds to start my suspension rebuild. Super jealous on the machinist tools! What shop do you work at in Atlanta?
      Our RestoMod Diary!

      El Mustache De La Resistance!

      Comment

      • Rdreas
        Advanced Member
        • Aug 2013
        • 164

        #48
        Originally posted by FreedomM3
        This thread is full of awesome! Great progress on the car! Hopefully I can get the funds to start my suspension rebuild. Super jealous on the machinist tools! What shop do you work at in Atlanta?
        Thanks man! I work at Superstar customs in lilburn, we do a lot of widebodies and air ride. We have a huge lathe at the ship too that the landlord keeps trying to sell me but I'm kinda broke at the moment.

        Comment

        • FreedomM3
          Advanced Member
          • Aug 2015
          • 191

          #49
          You work with Bucky?!
          Our RestoMod Diary!

          El Mustache De La Resistance!

          Comment

          • Rdreas
            Advanced Member
            • Aug 2013
            • 164

            #50
            Originally posted by FreedomM3
            You work with Bucky?!
            Yup! Just me and bucky at the moment lol. Know any body guys who need work?

            Comment

            • FreedomM3
              Advanced Member
              • Aug 2015
              • 191

              #51
              Nice. Not currently. How much to grind down the nut on an E90 top hat for me?



              It's Fernando from Zen.
              Our RestoMod Diary!

              El Mustache De La Resistance!

              Comment

              • Rdreas
                Advanced Member
                • Aug 2013
                • 164

                #52
                Originally posted by FreedomM3
                Nice. Not currently. How much to grind down the nut on an E90 top hat for me?



                It's Fernando from Zen.
                I thought e90 top hats were a bolt on? He didn't know but I'm sure if you brought it by we could take care if it. I'm not sure if we've met but I stopped by the zen tent at nopi and hung out with tae for a little bit.

                Comment

                • Tdurr
                  Noobie
                  • Nov 2015
                  • 2

                  #53



                  Cuz someone doesn't like to post updates of their own car.

                  Comment

                  • Rdreas
                    Advanced Member
                    • Aug 2013
                    • 164

                    #54
                    So first update in quite a while but there have been updates. First and foremost bought some style 5s in January and debated having them filled and redrilled because I didn't want to run adapters or e36 m3 parts. Ended up the full and drill was not going to be cost effective and ended up going with a hub adapter kit for the fronts. 20160530_151038 by Rdreas, on Flickr
                    Oh yeah and e38 brembos!
                    20160530_152152 by Rdreas, on Flickr
                    Had to run spacers to get the wheels to fit as well as more camber then I'd like and 195 tires which are a baby stretch. Before
                    IMG_20160530_153023 by Rdreas, on Flickr
                    After
                    20160601_211700 by Rdreas, on Flickr
                    Little size comparison of rotors
                    20160606_175505 by Rdreas, on Flickr
                    So then it was time to change the exhaust because it always hung lower than I liked, the welds were shit for the most part.
                    Snapchat-3306544970711243870 by Rdreas, on Flickr
                    So I got more V bands and cut the headers near the collectors.
                    Snapchat-3892432580229751541 by Rdreas, on Flickr
                    Before my headers ran right into a 2-1 collector which then had a vband on it. It was a cheap ebay stainless 2.5" flange but it ended up being the same size as a 3" quality flange so it had to move. I also decided I wanted the duals to run further back before merging. Tacked the flanges onto the header side while holding the short midsection pieces in place to make sure they were aimed in the right direction. Then sat the flex pipes on to begin mock up.
                    Snapchat-7923817113928793968 by Rdreas, on Flickr
                    Added some 45 bends
                    20160811_204750 by Rdreas, on Flickr
                    then another to send the exhaust straight down the trans tunnel
                    20160812_173857 by Rdreas, on Flickr
                    Tacked it all together under the car, which was really fun because it was all tig and I only have a foot pedal
                    Snapchat-6680172918427727976 by Rdreas, on Flickr
                    Did it one section at a time, all back purged, the collector is only on here for mock up. Welded the other side up and then put them back on the car and tacked on the collector. then purged it and burnt it in.
                    20160813_155622 by Rdreas, on Flickr
                    The rear was much more fun and involved a ton of swearing and not many in progress pictures, but here is how it came out all said and done.
                    Snapchat-1707467994047693762 by Rdreas, on Flickr
                    Where it passes under the subframe there is maybe a half inch, and the resonator is pretty damn close to the heat/debris shield for the driveshaft.
                    Then I had to go back to my favorite job of pulling the headers off.
                    Snapchat-3931938604551487171 by Rdreas, on Flickr
                    Snapchat-3064138793947447620 by Rdreas, on Flickr
                    Snapchat-5468158145080262342 by Rdreas, on Flickr
                    ended up having to drill the holes out on the rear header to be 1/16 bigger because before I took them off I had never been able to get all the studs to line up due to the epic ebay quality, but after drilling them they fit perfect and I was able to get all the studs in.
                    Last minute notes, I have been considering front mounting my style 5 faces in order to take camber out of the front. I would still have to run spacers but I want this thing as functional as possible. I haven't ever seen anyone do it with style 5s and I may have to weld up the valve stem hole and drill a new one on the back in order to do it but I am for sure going to try it out.
                    Last edited by Rdreas; 08-24-2016, 08:09 PM.

                    Comment

                    • 2mAn
                      SeƱior Mod
                      • Aug 2010
                      • 20087

                      #55
                      Nice to see there's progress
                      Simon
                      Current Cars:
                      -1966 Lotus Elan
                      -1986 German Car
                      -2006 Volkswagen Jetta TDI

                      Make R3V Great Again -2020

                      Comment

                      • Rdreas
                        Advanced Member
                        • Aug 2013
                        • 164

                        #56
                        Originally posted by 2mAn
                        Nice to see there's progress
                        It took a while, got the coils on and the wheels were scrubbing them. I had to decide what to do and some style 5s came along. I also moved mid January and work was super busy so I didn't have time to move the car for a month or so but I'm finally settled in and for the first time the car is actually where I live and I have all my tools which makes it way easier to get shit done. I bought some 5 lug trailing arms but haven't been able to meet the dude and pick them up. Also replaced my crank position and cam position sensors and repinned my harness so work has been happening just haven't been keeping up with this post as well.

                        Comment

                        • Tdurr
                          Noobie
                          • Nov 2015
                          • 2

                          #57
                          you should learn to save build thread pics not on snapchat first noob.
