    E30 S50 Turbo

    First off thanks again Steve(blunt) for all the help and for the parts.
    Car was a 91 318is.
    Now has a S50 with ZF and uuc evo3 ssk+dssr.
    Gc e36 for e30 coilovers 450f 700r.
    E36 m3 front brakes, e30 m3 rear.
    Hawk Hps pads.
    Stainless braided brake lines.
    Ate super blue.
    H&R sway bars.
    Kosie K1' & in the process of refinishing some e39 style 5'.

    Turbo build parts,
    Blunttech/good n tight manifold & downpipe.
    Garrett T3/60-1 .63ar turbo.
    TRM 60lb blow through tune.
    .140 mls.
    Arp 2000's.
    Turbosmart hypergate 45 external wastegate 7psi for now.
    Synapse bov.
    Southbend stg 3 clutch.
    Blueapplesoda Pnp innovate lc-1 wideband.
    Autometer boost gauge.



    This is just a test fit with the Style 5' so ride height is way off and tires will be proper size when they are refinished.


    Turbo build pics,
    Head off Havnt cleaned the block yet.

    Head back on and being torqued,















    Im almost done just waiting for the proper turbo oil feed fitting and the rallyroad steering column gauge mount. Then its off to get the exhaust made. After that is done im sure you can figure out whats next

    #2
    Damn that is a beast!! Nice work

    1991 LS1 Swapped 318is
    Instagram:
    https://instagram.com/saltybeast/
    LS Build Thread:
    https://www.r3vlimited.com/board/for...s-e30-ls1-swap

    Comment


      #3
      nice job brother I hope you show a good video pulling away on the highway:)

      Comment


        #4
        Looks good. I like how the intercooler is hidden..
        1988 325i Vert
        1991 318is Slicktop

        Comment


          #5
          Nice Synchronic BOV, those things hold boost real well, but are bulky as hell. Looks like a solid s50 turbo setup. Super Jealous. :bow:

          Comment


            #6
            Thanks guys, there will be vids for sure once its up and running.

            Comment


              #7
              Looks great..!!!!! Keep us updated.
              Need a Turbo manifold? We have them in stock- Click here---> http://rapidspoolindustries.com/
              ____________________________
              E-mail Panayiotisx2@gmail.com
              Dyno vid http://www.youtube.com/watch?v=C7aM7..._order&list=UL

              Comment


                #8
                Well balanced e30. Engine, suspension, brakes I'll click the "like" button.

                Comment


                  #9
                  awesome!
                  another local turbo e30!

                  keep up the good work man.



                  mtech1/2jzgte/r154/275tire
                  function>form

                  Comment


                    #10
                    Nice man! Nice
                    '87 325ic, powered by S50.

                    Comment


                      #11
                      are you running S.A management or chip if chip which one

                      Comment


                        #12
                        Originally posted by dmoney(AB) View Post
                        awesome!
                        another local turbo e30!

                        keep up the good work man.
                        Thanks, There's a few turbo e30's kicking around lots of 24v swaps going on that should be done this year. Do you ever make it down to Calgary or do you live mainly in fort mac?

                        Tuning is done with Trm's blow through tune with 60lb injectors.

                        Comment


                          #13
                          how much are they saying potential gain with that set up

                          Comment


                            #14
                            Badass
                            sigpic

                            Comment


                              #15
                              any reason you are running bov pre turbo instead of pre throttle body?
