E30 M42 Touring -92 // bagged + turbo build thread ** #119 Dyno 593hp/611nm @hubs

[JuusoIemel]

haha yes i remember your burnout, that might be a good idea too have you already installed oil cooler to yours?

Not yet, but i'm planning to do a PWM controlled oil pump that sucks oil straight from oil pan and sends it to the cooler, and then back to oil pan.
Should be a fairy simple system.
Dunno why, but im not really a fan of those oli filter housing systems.

[econti]

Not yet, but i'm planning to do a PWM controlled oil pump that sucks oil straight from oil pan and sends it to the cooler, and then back to oil pan.
Should be a fairy simple system.
Dunno why, but im not really a fan of those oli filter housing systems.

I actually have a plate that eliminates the entire factory filter and housing, the previous owner ran line engine > separate filter > cooler > engine.
It is lurid blue and red but if you want I'll post some pics. Doesn't seem too complex for someone to make either

[krisu]

Not yet, but i'm planning to do a PWM controlled oil pump that sucks oil straight from oil pan and sends it to the cooler, and then back to oil pan.
Should be a fairy simple system.
Dunno why, but im not really a fan of those oli filter housing systems.

not a bad idea at all. might consider that myself too!

I actually have a plate that eliminates the entire factory filter and housing, the previous owner ran line engine > separate filter > cooler > engine.
It is lurid blue and red but if you want I'll post some pics. Doesn't seem too complex for someone to make either

i've seen one of those before on someones build.

[krisu]

bimmerparty 2019 is over for this year and it was hell alot of fun! didnt test the car on 1/4 mile cause i was so hangover lmao. but i went to 700meter speedtest and burnout competition ofcourse! 700meter speedtest result 196km/h.

burnout went okay but i had some issues cause my tank was not full of ethanol, and then the fuel pump received air.. and the car just "died". need to fix that with fuel surge tank and external pump.

[krisu]

road to home from bimmerparty didn't go so well haha! car started to overheat and make pressure to coolingsystem, i kinda figured right away its the headgasket again. well i was almost home it was like 5 miles away from my garage so its all fine. this headgasket survived over 3000 miles on 26psi! overall i have been driving with this stock engine boosted almost 10k miles! tough little fucker

i was about to just put a new headgasket but the second cylinder looks pretty rough so i dont think its gonna work for long anymore.. well good thing i have prepared for this and i got stroker bottom end already good to go.

heres some pics from garage and current situation!





took the head off last weekend and the second cylinder is pretty rough, heres some pics

[paynemw]

I love the black kidneys with grey paint. This car and engine build are incredible. Cheers to you good sir.

[krisu]

I love the black kidneys with grey paint. This car and engine build are incredible. Cheers to you good sir.

thanks! ;D

[krisu]

update, rest of the engine out! left the gearbox inplace because i don't need to do anything to it. here is some pictures how it is sitting atm









also checked how my second cylinder piston looked, it actually wasnt even that bad, probably could have driven the rest of the summer with new headgasket only, well whatever

[968Reckless]

Great build, love those burn out pics with the mountains.


Sent from my iPhone using Tapatalk

[krisu]

Great build, love those burn out pics with the mountains.


Sent from my iPhone using Tapatalk

thanks !

[krisu]

sold the old garrett turbo and time for an upgrade, Precision 5558 GEN2 vband inlet/outlet .82ar. also bought 46mm precision wastegate. my goal for next summer is +600hp



block is almost ready, only missing paint

m47 crank 88mm, block bore 85mm
mitsubishi evo wössner pistons, 28,3mm compression height with modified valve relief pockets
140mm max speeding connecting rods
king racing bearings
headgasket is going to be 2mm athena coopering, and then compression ratio will be ~~9.56





new head is from e36 m42, ported and straightened head with new valve seats. polished e36 6mm valves, crmo retainers and e30 m42 double springs. also hydraulic vag ina lifters which are alot lighter than stock ones.

plan is to grind stock cams to get somewhere between 260°-270° and lift close to 10-10.5. if possible

[econti]

Beautiful port work, very interested to see how the maxspeedingrods go

[jeenyus]

great work! look forward to the new turbo!

[krisu]

hi all, have not used the forum since it got updated, my bad! here is some photos from last septembers performance bmw magazine, my car got featured! i will update soon how the build is going atm in garage!

these are the last photos from old setup, pictures taken by Jape Tiitinen.

[econti]

Your car is stunning in every way
