I couldn't imagine living in Winnipeg, their average temperature for the month of December was like -20C, on new years eve they set a record low of something like -38C before wind chill.... and when it's not an arctic tundra there it's a flooded swamp full of mosquitos..... FFFFFF that lol

[JCarp90]

[eurolife]

I looked and didn't see (might have overlooked it), but what are your plans for the TPS?

[Bullet Ride]

I looked and didn't see (might have overlooked it), but what are your plans for the TPS?

I'm running stand alone and the throttle bodies have a 3 wire TPS, all I have to do wire it in to the harness and re-calibrate in Tunerstudio.

It looks like it's finally going to be somewhat warm next week.... finally... I can actually work out in the garage. Unfortunately the E30 is in the shed out back, it'll take at least a week of warm weather before enough snow melts that I can get it out and up to the garage.

[eurolife]

Mind if I PM you with a few questions?

[Bullet Ride]

Mind if I PM you with a few questions?

Sure, go ahead.

[evoDRichie]

awesome looks great also in your sig are them style 10s... they look really good

[Bullet Ride]

awesome looks great also in your sig are them style 10s... they look really good

Yeah, they are 15x7 style 10 wheels painted Chevy orange.

And there should be some updates on this project soon. I've got all of the pieces now to finish up the throttle linkage, and I've got some parts to make a couple of vacuum manifolds.

[Bullet Ride]

Oh snap...


I'll do some more write up with pictures when I get a chance.

[downforce22]

Need more updates!!

[Bullet Ride]

Need more updates!!

Here's an update.... I started the car this evening.... and it runs!

More coming soon :pimp:

[Bullet Ride]

And I guess I can leave this here in the meantime...

[ApexGoblin]

looks good man, keep up the work, interested to see how you get it all to run

[bmwandhonda]

awesome!!

[Bullet Ride]

Ok so a little bit of write up to try and highlight some of the key things I had to do to finish up the mechanical bits on this project...

In order to shorten up the cables that came with the throttle bodies to use for this project I needed a few little bits and pieces like cable ends, ferules, and threaded adjusters. I figured it'd be easy to find this stuff, but apparently I was wrong. I went to two local motorcycle shops and a bicycle shop and couldn't find what I was looking for. After some searching and a few emails I got all the parts I needed for about $12 shipped from here http://www.venhill.co.uk/Cables_-_Co...ble_Components

After measuring and trimming the cables I put them in the bench vise making sure to put on the threaded adjusters and the cap for the cable joiner first because once the ends are soldered on the cables can't come through the cap of the joiner ...



Then I put on the cable ends and frayed the end of the cable to keep them from coming off...



And used a torch and some solder to fill in the ends...



The two cables join together with this brass piece that slides into the aluminum tube and the caps keep everything inside...



Then I machined up a clevis to connect the cable to the arm. There's a small diameter hole in it and a couple of set screws to crush the cable and hold it in place...



Then I figured I'd go a little steam punk with the vacuum manifolds so I went and bought some 1" copper tube and brass barbs. When drilling the holes in the copper I made sure to drill them so I could run a 1/8-27 NPT tap into the hole. That way I could thread the fittings in and crank them tight as well as making sure they go in straight...



The initial thought was to make a manifold for each set of throttle bodies and use one to fun the FPR and MAP sensor and the other solely for the brake booster. I figured if I was going to attempt to run the car off MAP before trying alpha-n I wouldn't want the booster pulling off of the same manifold as the MAP sensor. Since there is a lot less volume than the stock manifold I though that it might end up causing problems. I thought that where the fuel rails use to be on the throttle bodies would be a good spot...



So I soldered away...




Then one day after work I was looking at the weldment for my linkage and thought that it was too heavy, so I started drawing on it with marker...



Because sharpie marker magically makes things lighter...



It was actually a rough guide for where I'd drill holes to give it the superleggera treatment. I never did take a picture of that, but it's nothing special, just drilling holes.

After that I set about putting everything back onto the car for the final test fit just to make sure everything would work the way it should. Once I got the linkage on the car with the cables a couple issues became glaringly obvious.

Firstly, I was building the throttle linkage on a motor that was sitting perfectly vertical on an engine stand. I never really considered too deeply the angle at which the throttle cable in the engine bay would have to enter the linkage in order for it to work properly. The plane of my linkage was parallel with the valve cover, but on the car the valve cover sits at quite an angle, I needed the plane of my linkage to be parallel with the ground, which meant I had to cut it off and re-position it.

The second issue that arose once the linkage was at the correct angle was that the pedal force required to open all 6 throttles was massive, like as stiff as my clutch pedal. That wasn't acceptable, but on top of that the fixed end of the throttle cable was now mounted to the bracket where the throttle cable was secured to the throttle body, which is only connected to the manifold by silicone couplers, so every time I pressed the gas the one set of throttle bodies was flexing up and down due to the heavy spring force.

I decided that I needed to tie the cable mount back to something solid. The simplest solution to me was to weld a brace that went back to the throttle linkage...



That made the throttle assembly nice and rigid and eliminated the flex.

Then I soldered on some mounting tabs to the vacuum manifold so it could mount up to the throttle bodies...



Unfortunately the brake booster got in the way of the second manifold so I had to shorten it...



After that I took apart the throttle bodies to remove some springs. Each set has 3 springs, so there were 6 springs in total, compare that to the 2 springs on the stock throttle body... it definitely felt 3x stiffer lol. Luckily it was easy to remove 2 of the 3 springs from each set of throttle bodies. With only one spring per set of throttle bodies the pedal felt much more like the stock pedal.

I realize that there is some inherent risk with removing the springs. Each throttle body should have a spring in case part of the linkage malfunctions or falls off, that way the throttle will always tend to shut. Without a spring, if something broke it could flap open and send one cylinder to WOT. I'm fairly confident in the robustness of the mechanism, but I'll make sure to inspect the parts on a regular basis to make sure everything is as it should be.

After that I took everything apart, cleaned it up, painted the linkage and manifold black and then put it all back together...



The throttle bodies came with a 3 wire TPS. I figured out which wires had to go where and spliced them into the harness. This TPS works the opposite as the E36 TPS I was using previously though. At zero throttle the voltage is high and at WOT the voltage is low. I did the calibration in tunerstudio and the TPS gauge was reading what my pedal was reading with a nice stable signal. However, much like the E36 TPS I had once the car was running the TPS signal became unstable. I figure there's probably some sort of grounding issue with the harness somewhere that's causing feedback, either that or it's a result of my alternator not giving a stable voltage signal (I have the pulsing headlights when the car is sitting idling currently... I need an alternator rebuild)

Also worth mentioning is that while the paint on the manifold was drying I synced up each set of throttle bodies. I did it using the shank of a very small diameter drill as a feeler gauge. I cranked the idle screw open on the throttle body until the drill would slide past the gap with some drag, much like doing a valve adjustment. Then I adjusted the sync screws on the other two throttles until all 3 had the same amount of drag then just cranked the idle screw back out. Once both sets were on the car I used the idle screw on the throttle linkage to open both sets and then used the threaded adjusters on the cables to make sure the drag felt the same across both sets. This should get me fairly close, and at some point I'll get a couple of vacuum gauges just to get them dialed in dead nuts.

Anyway, that pretty much sums up the mechanical side of things. The car did fire up and the MAP signal was stable enough for the car to idle normally.

Now the fuel maps need to be completely re-tuned. So I'm slowly working on that.
