Update with some pics from the rear bumper refit.
Quick and easy job when the bumper is straight.
Firstly, the diagram in Real OEM shows different fixing arrangements for the bumper end caps.
Plus it's not really clear.
Plastic end cap is attached to the bumper by 2x phillips head screws per side (#25).
The diagram shows a hex head.
The bumper end cap shows two options:
A) A hex head screw & short rubber hose as a seal (#17 & #18)
B) A hex net, spacer, rubber washer , flat washer and hex bolt (#24, 23, 22, 21 & 20)
Mine had neither.
Just a simple hex head screw and speed nut clipped into the bumper end cap.
Note the different length screws.
Left = shorter = screwed through the quarter panel from inside the trunk.
Right = longer = screwed through the rear section of the wheel arch
Firstly, gave the inside of the bumper a spray with Penetrol.
It's a great product to defend against moisture & rust and dries to a flexible film.
Kinda like the cosmoline style coating the factory applied to prevent corrosion.
Protect the bumper with rolled-up towels ready for fitting.
With the bracket already attached to the bumper, offer the bumper up and hand tighten the nuts bracket nuts from inside the trunk.
For the sides. no need to remove the trunk lining - I assume the Germans thought about access to the screws?
Use a screwdriver to help locate & centre the bumper sides.
Pro tip...
Use a magnetised socket or bit of Plasti Tackon the hex head.
The left over self-adhesive (from the spoiler) also help keep things dust and water tight.
Loosely tighten while you get the bumper alignment right...
This socket & extension combination gives good access to the bumper bracket nut up near the rear muffler
More jiggling and tightening to even the gaps and centre the bumper...
- bumper to rear brackets
- rear brackets to body
- bumper sides & end caps
It actually came up really well!
Plus a shiny new boot roundel.
Finally the clean rear trunk liner.
Which had a few repairs done with shoe glue and duct tape to keep things together for another 30+ years.
The re-chromed bumper, new end cap, refurbished spoiler, polished taillights and paint correction really lifts the back of the car.
FINALLY the front and back are looking great and water tight.
