    Also can you get a new bolt relatively easily it may be worth cutting mashing and buggering up a 10 dollar bolt to get it out with less frustration than trying to keep it serviceable, as you have heat treated it and likely removed some or all of its spec'd strength as a critical suspension component fastener
    Originally posted by Fusion
    If a car is the epitome of freedom, than an electric car is house arrest with your wife titty fucking your next door neighbor.
    The American Republic will endure until the day Congress discovers that it can bribe the public with the public's money. -Alexis de Tocqueville


    The Desire to Save Humanity is Always a False Front for the Urge to Rule it- H. L. Mencken

    Necessity is the plea for every infringement of human freedom. It is the argument of tyrants.
    William Pitt-

    Comment


      Not trying to save it. New bolt and nut on the way.

      Comment


        good deal that makes its much easier, and less of a PIA.

        post up what you did to get freed up, I am always intrested on how people solve stuff like this to file away for future use if need be
        Originally posted by Fusion
        If a car is the epitome of freedom, than an electric car is house arrest with your wife titty fucking your next door neighbor.
        The American Republic will endure until the day Congress discovers that it can bribe the public with the public's money. -Alexis de Tocqueville


        The Desire to Save Humanity is Always a False Front for the Urge to Rule it- H. L. Mencken

        Necessity is the plea for every infringement of human freedom. It is the argument of tyrants.
        William Pitt-

        Comment


          Turned out pretty easy. Generic DeWalt rental sawzall, with my Diablo carbide tipped blade.

          We only had it high enough to take off the wheel, and then collapsed the suspension, so we couldn't raise it higher safely. That meant we couldn't hold the saw horizontally and get at the bushing and push down. I had to be on my back with my left forearm pushing up on the blade and my right middle finder hooked in the trigger upside down.

          Zip zip, went right through.

          I didn't want to bugger up the welded and machined bosses on his control arms, so I pushed the blade tight to the strut and cut all the way through the steel bushing and bolt together. Took the paint off the blade, but no discernible wear on the teeth.

          Control arm looking straight up. Forward is up in the pic. CV boot not far away, so careful with heat.

          Click image for larger version

Name:	under strut.JPG
Views:	22
Size:	49.3 KB
ID:	9906302

          Forward side of bushing much narrower.
          Click image for larger version

Name:	strut forward.JPG
Views:	16
Size:	38.5 KB
ID:	9906303

          Bolt head recessed in arm.
          Click image for larger version

Name:	bolt head.JPG
Views:	17
Size:	46.3 KB
ID:	9906304

          Nice tidy mushroom.
          Click image for larger version

Name:	mushroom.JPG
Views:	16
Size:	36.5 KB
ID:	9906305

          That's a rust drip of PB after days of soaking. No movement at all.
          Click image for larger version

Name:	strut bushing.JPG
Views:	16
Size:	64.5 KB
ID:	9906306

          Comment


            The rear side...ZING!
            Click image for larger version

Name:	cut red.JPG
Views:	19
Size:	51.2 KB
ID:	9906311
            The forward side...thin-sliced roast beef!
            Click image for larger version

Name:	thin slice.JPG
Views:	17
Size:	58.9 KB
ID:	9906312

            The short bit of bolt head fell out of here, but the rest is bonded for good.
            Click image for larger version

Name:	thin slice 2.JPG
Views:	16
Size:	74.7 KB
ID:	9906313

            Click image for larger version

Name:	head cut.JPG
Views:	16
Size:	47.7 KB
ID:	9906314
            Just for fun, we pounded on this bolt with a big punch and a sledge to see if we might have broken the bond - zero movement. It was never coming out.
            Click image for larger version

Name:	strut cut.JPG
Views:	16
Size:	56.4 KB
ID:	9906315




            Comment


              5 pics per post it says.......


              Click image for larger version  Name:	bolt + sleeve.JPG Views:	0 Size:	38.5 KB ID:	9906317

              Click image for larger version  Name:	bolt glove.JPG Views:	0 Size:	70.3 KB ID:	9906318

              Shiny new bolt. Nut appears to be the oval self-locking type. We cranked it on with the impact. Book says 184 ft-lbs, so we were close with our Harbor Fright. Buttered the sleeve and the bolt with anti-seize.
              Click image for larger version  Name:	New bolt.JPG Views:	0 Size:	49.8 KB ID:	9906319

              This...is what you need.
              Click image for larger version  Name:	Diablo.JPG Views:	0 Size:	64.1 KB ID:	9906320


              It was fun to put the fuses back in and fire it up. It pumps up quick! Usually more rear first, then the fronts level up. The compressor went off in a couple of minutes, and that's from completely empty. It used to run for a few blocks after you warmed it up. So that strut had to be leaking, and it's hard to find because the bellows folds down over itself, and often covers up the leak and pushes it shut. And you don't drive around in high mode with the struts extended - I think at 25 or 30 it automatically lowers back to normal height.

              ​​​​​​​If it starts to droop in a week, we'll be pissed.
              Last edited by LateFan; 02-17-2020, 04:15 PM.

              Comment


                OHHH I Didnt know the control arm was "hollow" on the underside, I assumed there was a flat bit of steel boxed across the bottom, (if you mentioned that I must have missed that part) that would not have allowed semi easy access to cut that SOB out. You defiantly did the right thing, and I would have likey done it the very same way, or maybe used a wizz wheel cutter. Great job and glad to see you got it all handled this weekend and everything thing went well
