Originally posted by kylelauffer View Posthow much are bmw e30 depos worth? like the real ones. they have modern style clip in for lights though. brand new in the box?'72 2002 | '74 3.0cs | '88 M5 | '89 330is | '89 M3 | '11 328i
Comment
-
I'm trying to button up the last of the wiring on my m50nv swap and I've got some confusing wiring diagram issues. The ETM for my harness shows CTS on pin 12 of the x20 (in Brown/Violet) while just a few pages earlier it shows the CEL light going to pin 12 on the x20 in Gray on one side and Brown/Violet on the other. My harness has Brown/violet on both sides. Where does the CEL go?84 325e - 91 325i - 92 318 touring - 91 Trans Am - 01 S4 avant - 03 S-type R - 96 F350 - 15 SS - 84 Biturbo - 91 Defender
Comment
-
Here is how you wire your early C101: http://www.e30zone.net/e30zonewiki/index.php/C101'72 2002 | '74 3.0cs | '88 M5 | '89 330is | '89 M3 | '11 328i
Comment
-
That's incredibly helpful and will quicken the rest of my wiring; but I'm more concerned with the engine side harness (an e34 version) as the ETM shows two wires of completely different functions on the same pin?
By your response I'm going to presume that I can't run my CEL to the factory Service Light?84 325e - 91 325i - 92 318 touring - 91 Trans Am - 01 S4 avant - 03 S-type R - 96 F350 - 15 SS - 84 Biturbo - 91 Defender
Comment
-
Originally posted by iansane View PostThat's incredibly helpful and will quicken the rest of my wiring; but I'm more concerned with the engine side harness (an e34 version) as the ETM shows two wires of completely different functions on the same pin?
By your response I'm going to presume that I can't run my CEL to the factory Service Light?'72 2002 | '74 3.0cs | '88 M5 | '89 330is | '89 M3 | '11 328i
Comment
-
Furthermore, I can't find more than one or two wire colors that ANY ETM list as being correct.
That says the CEL goes through pin12
Those come from the same ETM, just a few pages away. Perplexing.84 325e - 91 325i - 92 318 touring - 91 Trans Am - 01 S4 avant - 03 S-type R - 96 F350 - 15 SS - 84 Biturbo - 91 Defender
Comment
-
I don't know how to find a pins usage in the ETM without searching a component specifically.
For Check Engine;
'91 says pin 12 gray
'92 says pin 6 gray
'93 says pin 8 gray
I would just chock this up as the guy I bought the engine/harness from not actually knowing what year it was but since the '91 ETM assigns two functions to pin 12 I'm confused. I mean it seems obvious that it's the CTS.84 325e - 91 325i - 92 318 touring - 91 Trans Am - 01 S4 avant - 03 S-type R - 96 F350 - 15 SS - 84 Biturbo - 91 Defender
