    S54/iBooster update: It is NOT possible to run an iBooster with a CSL style CF airbox. The master cylinder comes into contact with the airbox. The next option is to use the Race German Booster relocation template to slot the booster over 1/2 inch. But from eye balling it, it doesnt seem like that solution will work either.
    -Brad, AlphaTeam Motorwerks, LLC
    91' 318iS - S54/6MT Swapped
    08' E90 M3 6MT - Daily
    04' Chevy Duramax CCLB - Work Truck/Hauler

    Originally posted by IronJoe
    Alpha Team: running through e30s, gringo icebergs, and 19 yr olds.

    Originally posted by 2mAn
    Brads a standup guy even though he likes buttsex


      where are ya'll tapping into for 12v switch?


        Hey every one I've been a lurker for a long time so this is my first post. I'm on my 3rd E30 , previously both were 20V swaps .
        Currently I have a 2JZGTE VVTI swap with a PMC adapter with a GS6-53BZ 6mt out of a 335i.

        I'm currently running the Model S booster . I was unable to clear the Model S master so I got a Chevy Bolt Ibooster as the outlets are rotated 90*. The Bolt Ibooster does not straight bolt on to the fire wall but the Iboosters of this gen are all the same physically , as in the mounting flange for the master is the same and so is the mounting flange for the Fire wall adapter.
        I still had to run it upside down.
        Model S master
        Click image for larger version

Name:	IMG_20230126_155012.jpg
Views:	93
Size:	184.3 KB
ID:	10100684
        Bolt master
        Click image for larger version

Name:	IMG20230308000754.jpg
Views:	79
Size:	93.4 KB
ID:	10100685
        I've Managed to make it work with 1/4" of clearance but had to make a custom reservoir and use barb adapters with custom retainer plate to keep it from popping out
        Click image for larger version

Name:	IMG20230308000806.jpg
Views:	80
Size:	107.1 KB
ID:	10100687

        Click image for larger version

Name:	IMG20230404200058.jpg
Views:	78
Size:	139.3 KB
ID:	10100686

        Click image for larger version

Name:	IMG20230404200110.jpg
Views:	78
Size:	154.8 KB
ID:	10100688

        Anyway I'm kinda dealing with an issue of Over performance if you can call it that.

        I'm running Willwood BBK 6 piston front and 4 piston rear.
        when I lightly tap the brakes rolling 5-10mph you can knock your teeth out on the steering wheel that's how hard the car stops.
        The brakes are super sensitive , not sure if this is due to the different master or the BBK or the combination of both.

        I Know there's not that many people run this kit but does anyone have any suggestions?
        I wonder if the module is programed different for the Model S vs the chevy bolt as in More assistance for the much heavier car.

        I do have the whole Chevy bolt Ibooster and I'm planning to swap that in in place of the Model S booster and hope that its programmed for less assistance for the lighter car.

        Also the Chevy bolt master has a marking on the body P and S I'm assuming that's Primary and Secondary cylinder , so I have the P connected to the front and the S to the rear brakes. Maybe that is backwards , I could not find any info on the master.

        Any info is appreciated



          I have not tested it, and its possibly unsafe, but in theory throwing in a restistance in the series for main power for a electric motor should reduce its power output.

          Its more likely a master/caliper ratio problem: smaller master will give you longer throw, however, it will also allow a small force on the pedal to give a higher force output of the calipers. 23mm is for small calipers. Its even smaller than the e-golf one which is 23.81.

          I suggest trying the master from the Tesla s. Its 26mm. Tesla has both gen 1 and 2 iboosters, so try and get the correct one in case they are not same.

          You can calculate the ratio of the tesla or other cars master/calipers, and check if its going to somewhat match your setup first. Bosch produce masters for a bunch of cars, its possible there are other ones out there we dont know about that fit or can be made to fit, but check tesla one first.

          My setup is also quite sensitive which is fine for the streets, but not like you are describing. It took some getting used to. This is running on the e32 740i brakes

          If you try it, please keep me updated.

          Also, do you have some info on brake bias? im running the original 2-door rear brake bias valve, and i feel like i almost dont have rear brakes. What are people running?
